LED Traffic Signal Lamps
Central Light Source LED Traffic Lights
Central Light Source LED Traffic Lights are energy-efficient products and systems that are primary for smooth and safe vehicular as well as pedestrian movement. These are high quality and maintenance-free with clear visibility in all-weather, all-light conditions.
Key Benefits
-
No LED dots visible, very uniform signal glow – central light source
-
Highest anti-phantom performance (class 5)
-
Lowest power consumption and brilliant light output
-
All products traceable by serial number
-
Custom-made masks allow any symbol display
-
Life cycle > 5 years
-
Optimum heat balance reduces degradation to a minimum
-
Automatic light compensation in case of diode failure
-
Proven technology
-
VDE-compliant FUTURLED3 modules available
-
Also available with clear lens
-
Modules compliant to local norms available (UK, South Africa)
-
Optical monitoring available
-
Compatible with standard-conforming signal head housings/p>
Technical Details 230V
| Daimeter | 100 mm | 210 mm | 300 mm |
| Luminous intensity acc. to EN12368 | Not applicable | red > 200 cd amber > 200 cd green > 200 cd |
red > 400 cd amber > 400 cd green > 400 cd |
| Optical performance acc. to EN12368 | Not applicable | B2/1, W | |
| Colour acc. to EN12368 | Red 613.5 - 631 nm, amber 585 - 597 nm, green 498.5-508 nm, white 5000 — 7000 K | ||
| Uniformity of Luminance acc. to EN12368 | Not applicable | better than 1 : 2.5 | |
| LED type | High Flux | ||
| Phantom light class | Not applicable | Class 5 | |
| Power Factor | > 0,9 | ||
| Operating Voltage bright mode/dimmed mode | 196 — 265 V / n.a. | 196 — 265V / 160V — 180 V (light output is reduced to app. 50 % of normal level if the input voltage is decreased) | |
| Frequency | 45-55Hz | ||
| Power consumption: typically bright mode / dimmed ,mode | Red 5W / n.a. amber 5 W / n.a. green 5 W / n.a. white 5 W / n.a. | red 8W/ 4 Wamber 8W/ 4Wgreen 9W/4.5W white 9 W / 4.5 W | |
| EMC | acc. EN 50293 | ||
| Cable | 2x 0.75 mm2,1 m | ||
| Ambient temperature range acc. to EN12368 | ClassA, B, C Safety Class II acc. to EN |
||
| Protection Class | 60598 | ||
| Tightness | IP 65 acc. to EN 60598 | ||
| Impact resistance | Class 103; acc. to EN 60598-1 | ||
| Material of lens/ housing | UV-stabilized polycarbonate | ||
| Weight | < 0.25 kg | < 1.0 kg | < 1.5 kg |
| Dimensions (incl. front lens) | 0 108 x 72 mm | 0 210 x 117 mm | 0 300 x 149 mm |
